The Best EL34 / 6CA7 / KT77 Power Tubes - Reviews and Guide

Are you looking for the very best EL34 power tubes for your vacuum tube amplifier? This is the place to start. Check out the following tube reviews for guidance in getting the best possible tone out of your tube amp.

Other common substitutes for EL34 vacuum tubes are 6CA7 and KT77 tubes. Although not identical, they are close enough to be considered direct substitutes in almost any instance.

If you're not sure if your tubes are bad, we have some great trouble-shooting tips to help you find out. You won't need a tube tester either, so you can try these suggestions right at home. You'll find more info in our blog article, "How To Tell If Your Tube Is Bad".

(View our complete selection of EL34 / 6CA7 / KT77 vacuum tubes)

Review Notes

Tube reviews by John Templeton

It’s not easy evaluating something as subjective as sound. We each have our own personal taste in music and the way it sounds. I have attempted to add some objectivity by defining some aspects of tube performance that affect any listener, regardless of application, budget or musical taste. The EL34 is a very popular tube and is used in equipment that creates as well as reproduces music. This testing was done using tube guitar amplifiers. With this in mind, consideration has been given to construction quality and mechanical noise. These factors are important to musicians but may not be an issue when a tube is used in the home or studio.

Test Amps:

1973 Marshall Super Lead model 1959: This amp is completely stock using NOS pre-amp tubes. The sound was reproduced through a 1971 Marshal cabinet with 4 Celestion G12M "greenback" speakers.

1970 Marshall Bluesbreaker 2x12 combo

Class A Combo: Designed and built by Bernard Raunig. This is a true single ended class A amplifier, using a 5Y3 rectifier and a single 5691 pre-amp tube. With a volume and single tone control this amp really lets you hear the tonal differences between the tubes.






EL34 Reviews

Electro Harmonix 6CA7-EH - At last something to replace the hole left since the EI 6CA7 went out of stock. These tubes sound every bit as good as the old EI tubes and are probably my favorite tubes for Hiwatt guitar amplifiers. It’s like they were made for each other. These tubes are like EL34’s on steroids. They handle high voltage and current without problems. As mentioned, there is nothing like a Hiwatt head powered by 6CA7 tubes and driving a 4x12 cab loaded with Fane speakers. This is classic rock tone at its finest. It’s the sound of Pete Townsend and The Who. The 6CA7 tube has more headroom than an EL34 and by the time you get it really crunchy sounding your pants are flapping in the breeze. Just the right amount of compression for great thick rock tone. Biasing levels can be dialed in from warm to hot without causing significant tonal changes. The EH is well constructed and should not pose any noise problems. If using these tubes in more reasonable systems the EH 6CA7 is capable of some really nice clean tones thanks to that extra headroom. If you want early Van Halen, these are not the tubes for you. If you want something loud and proud, you want to put the EH 6CA7 in your amp.

Back to top

Gold Lion KT77 - This tube was a treat to listen to. Since many of us have never actually listened to a KT77 tube from the original producer, I can not say that they nailed the reproduction. You really have to think of this tube as its own entity. Here is what I can tell you about it. The Gold Lion KT77 tube is a drop in replacement for an EL34 or 6CA7. The sound however is not typical of an EL34 or 6CA7. It is more of a hybrid. The tube delivers all the mid punch you would expect in an EL34 but also has a top end that is more open and bright. It’s definitely got a bit of a 6L6 designed into it. I tested it in a Marshall 2205 50w head and was able to get that '70’s rock sound but with some bias adjustment could also dial in a VOX-like chime. This really has to be looked at as a new choice in power tubes. If you have a Marshall and never could decide if 6550 or EL34 tube was the way to go, you now have a third option.

Back to top

JJ 6CA7 - Prior to this tube being introduced the choice in a 6CA7 tube was NOS or the Electro Harmonics 6CA7EH. JJ 6CA7 has provided another choice and another price point. JJ tubes tend to be well made and this model fits well into the family. Nice construction, good glass, and the base and pins are well assembled. Although this is a replacement for the EL34 tube, the 6CA7 tube looks nothing like a pentode. In fact, an examination reveals what look like the beam forming plates you usually see on a 6L6 power tetrode. I’m not 100% sure of what’s going on in there. The JJ 6CA7 tube looks and sounds like a 6L6 but biases like an EL34. When installed in a 50W Hiwatt head these tubes just roar. It’s a classic sound for beefy rock anthems. The sound is firm and articulate. A number of customers have reported that this 6CA7 tube is darker sounding. Your mileage may vary but I found nothing dark about them at all. Smooth yes, dark, not so much in my testing.

Back to top

JJ E34L (EL34) - Are you a fan of rock and roll music? If you answered yes and use EL34 tubes then this could be, your go-to bargain. JJ makes great tubes at affordable prices and the E34L tube is no exception. It is built in a very rugged package with thick glass and a welded plate assembly. Two mica spacers that feature a high number of support points at the top and bottom of the plate support the assembly.

Do not let the price of these tubes make you think they are anything but excellent. There is a tendency in the tube world to shy away from things that are reasonably priced. However, I would counter that today we need as many bargains as we can find, and this tube qualifies.

The sound of the JJ E34L tube is very much a rock sound. The bass is bold and the midrange is thick. High-end response is very good but not as bright as some of the Chinese models on the market today. The compression characteristics on the E34L do not really become noticeable until you push the tube into overdrive. This allows for a little more sparkle at lower volumes and an audible thickening of the sound as the volume goes up.

This is a good tube at a great price. If you want more high-end sparkle then the JJ EL34-II might be a better choice for a few more dollars. If you want to rock then the JJ E34L should meet all your needs.

Back to top

JJ EL34-II - JJ has upped their game with the new EL34 II tube, and the design change is truly big enough to warrant the use of the new name. Many companies put an existing tube into a new bottle, but JJ has done the opposite.

The familiar tall, dome topped bottle is still there but everything else has changed for the better. The new tube has a traditional EL34 tube plate structure but they have replaced the plate assembly with a slightly smaller unit that features crimped plates instead of spot welded plates. The crimping is clean and precise making a very solid and quiet assembly. The mica spacers are well formed and very secure. This looks more like something from Siemens than JJ.

Listening to this tube was a bit of a surprise because I usually find EL34 tubes to be a bit soft sounding, and this tube is different. There seems to be a bit more life in this tube as compared to the previous model. I found there to be a really nice top end that is smooth and free from harshness, while still delivering a nice bit of sparkle. At the other end of the spectrum I found the bass to be very firm and clear with no boominess. For guitar use the midrange is where the action is and this tube handles it nicely. I didn’t hear any honking Mids. It seems the design goal was to make something with broad frequency response that extends a little further than the standard JJ EL34 tube. The closest sounding match would be the Tung Sol EL34B tube.

This new tube has really earned the right to be labelled version II.

Back to top

JJ KT77 - The KT77 has been gone for many years and original NOS pieces are rare and expensive. JJ electronics has revived the design and released their own version. To my ears it sounds a lot like a 6L6 but has the heater current, max plate voltage and output rating of an EL34. The JJ KT77 has published specs that are identical to the original Genalex specs. The base has pin 1 included but there is no connection to any internal element. The sound is somewhere between an EL34 and a 6L6. Overall a nice balance of tone in bass, midrange and treble. The breakup is earlier than a 6L6 with more compression but not as compressed as the EL34. Unlike an EL34 this tube can be used in place of a 6L6 in Fender amps with minimal modifications. Vintage Fender amps usually use pins 1 and 6 as tie-off points for input grids and screen grids, mounting resistors on the socket. A standard EL34 can’t be plugged in because the input grid would be shorted to the suppressor grid via pin one. The KT77 avoids this. The only caveats are to ensure that your power transformer can supply an extra 500ma of heater current per tube and that the range of bias voltage adjustment is correct. If you have a Marshall amp and find EL34’s too compressed and 6550’s too crunchy the JJ KT77 may be just the ticket.

Back to top

Mullard EL34 - One of the most famous brands in the history of vacuum tubes now belongs to a different entity. Not unlike Tung-Sol and Gold Lion, this is a new-ish tube with an old name. Fortunately, the Mullard EL34 tube has a lot in common with the originals.

There seems to have been efforts made to make current production resemble the originals. The classic tall bottle with a flat top, featuring two large cooling wings attached to the support rods just below the getter assembly. It is a classic look for your audio equipment.

The sound of these tubes is pure EL34. Smooth and balanced overall, the frequency response is a bit softer in the midrange than some other models. Mullard EL34 tubes have a smooth, liquid feeling that is very different from a 6L6GC. Some people used to refer to this as the sound of a soft vacuum. I don’t know if the vacuum is any different, but the tube has no rough edges to speak of and has that slightly compressed sound at lower levels. When you push the Mullard, the compression becomes more noticeable and helps to build a very fluid sustain.

I really enjoy these in my old Dynaco Stereo 70 for their warmth. If you want something with bite for your guitar amp these would not be my first choice. Tung-Sol EL34B’s would probably be better. If you want to smooth your overall sound and tame harsh midrange response then these may be just what you are looking for.

Back to top

Preferred Series EL34 - In a market that has a lot of options for an EL34, this tube could be a stand out. The tube design is classic EL34, with the tall grey plate you would expect. The bottle is a bit wider than some EL34 tubes and is big enough for a 6L6. The glass is nice and thick. The mica’s in the Preferred Series EL34 are nice and thick and look to have a very snug fit. This should help eliminate microphonics and the tube I tested had none, so it must be working. The plate assembly is topped with a single, small, halo getter and two oversize cooling fins mounted to the support rods. Of course the base of the tube is the signature blue of the Preferred Series octal tubes.

The sound in my single ended test amp was great. I usually run a KT66 or 6550 in this amp but this little EL34 will be there for a while. The bottom end is amazing and the tube has tons of gain before it gets dirty. The real strength of this tube is the bass and midrange. Bass notes are rock solid and the mids are very rich and complex. The high end is very good but not bright. This tube really wants to be in your JCM 800 or other amp that can generate piercing top end. Marshall users could combine these output tubes with their beloved high-gain Chinese pre-amp tubes for some real punch. Palm muting chords with p-90’s or humbucking pickups produces some seriously percussive sound. The Preferred Series EL34 can keep up with anything on the market. The extended warranty of the Preferred Series combined with the tone and build quality make this an outstanding tube for home audio and musical instrument amplifiers.

Back to top

NOS Siemens / RFT EL34 - Back when we started doing reviews of EL34 tubes, an old and somewhat tired set of Siemens EL34 was used as the reference standard. To have them available again for what I consider to be a reasonable price is great. These are the real deal. I tested three pair of the NOS tubes with different “perfect pair” matching numbers just to see if there was consistency and I’m happy to report that when biased the same they were very consistent. When I think of German power tubes I think of a big warm sound that doesn’t cause listening fatigue after an hour of playing. Many will say that Telefunken is king but the Siemens brand was always under rated. I ran three different types of EL34 tubes through the Marshall in one night of testing and the Siemens was the only one that required me to reduce the bass response. These tubes are extremely warm sounding and if you have one of those amps that sounds thin at lower volume levels, these should take care of that problem in short order. Midrange response seemed slightly skewed toward the bass side. This is no doubt where the extra warmth is coming from. The high end was smooth and clear without a trace of harshness. Construction is very good with the straight, flat-top bottle that is characteristic of the Siemens EL34 tube. No issues at all with noise and this is likely because of the thick laminated plate structure. You can see how heavy these plated are by examining the four large crimps down each side of the plate. This is a great opportunity to own NOS EL34 tubes without breaking the bank. And based on Siemens track record they should last longer than anything being made today. Home audio, guitar amps and those big old Grundig and Normandy console stereo units will all benefit. Enjoy.

Back to top

Shuguang EL34-B - For many years no one would have believed that Chinese tube factories could turn out work of this quality. The construction of this tube is first class, with a well-supported plate structure that rests in a large straight bottle that tapers to a well finished brown base. These tubes represent a very solid piece of construction with almost no mechanical noise and an overall feeling of quality

The sound is loud and clear with a very nice sonic range. Not excessive in tops, mids, or bass, they are accurately described as well balanced. The sample tested had no audible microphonics and an average background noise level. Harmonic content was rich, lending that pleasant "swirl" and sustain that guitar players crave.

Back to top

Sovtek EL34WXT - Sovtek has come a long way with this tube since the EL34G. Construction has been improved greatly reducing mechanical noise. Very good sound but not in the same range as the Svetlana. It seems as if the frequency response has been shifted toward the midrange band. Harmonics are rich and fairly balanced but the high end can get a bit bright. Great in a darker sounding amplifier.

Back to top

Svetlana EL34 - The Svetlana EL34 tube is perfect for classic rock. The midrange is very pronounced and the high end is smooth. The bottom end response is not the best, but in a guitar amp it becomes a moot point. In the test amp the mids just rip through the mix. No guitar player is going to get lost in the mix using these bottles. These EL34 tubes deliver incredible crunch making them perfect for that ZZ Top, old EVH sound. Seven string down-strokers may not be as pleased because they don't have that crushing deep bottom end. (Note: the amp used for this review was done in a 100 watt Marshall JMP)

Back to top

Tungsol EL34B - The Tungsol EL34B tube is likely to become the #1 choice of currently produced EL34 tubes. The build construction is great all around and the move to welded plates will likely keep “EL34 rattle” to a minimum over time. The manufacturer claims that this tube has a hint of 6L6 in its tone thanks to manipulating the plate impedance. This is absolutely true, but the effect is most notable when playing clean and to a lesser extent when the tube is driven hard. At lower volume settings you hear a very pure balanced tone with a bit of the 6L6 sparkle in the higher frequencies while providing a midrange that is a little less prominent than most EL34 tubes. The tubes were very open and airy. The bottom end was percussive in the 2x12 open back combo. When driven into distortion it starts off a bit crunchy like a 6L6 but as you push it, the sound blooms into that singing EL34 tone with great sustain and modest compression. I love these tubes. Over the years I’ve tested many tubes but this is the first time I’ve had to tell myself to stop playing and get on to the next set!

Back to top

Winged "C" / SED EL34 - If you want one EL34 tube that will do anything the Winged "C"/SED EL34 tube is money well spent. There is ample bass response but it is firm and controlled. The mids are smooth and the top end shimmers. Nice swirling harmonic content. The construction of the tube is outstanding and I feel it contributes to the overall performance. Lots of clean headroom from this tube with a smooth transition into breakup. Probably great in home audio applications, but if you want raunch at lower volume levels keep reading.
Back to top
